3B³ stereo stiprintuvas

Bryston
5290
The Bryston 3B³ is dual-channel (stereo) amplifier designed for a wide range of audio/video systems which call for medium to high amounts of power, but wish to avoid sacrificing sonic accuracy and long-term reliability.

Features


– Active extremely low distortion input buffer
– Balanced and Single Ended audio inputs
– Selectable gain at 23 or 29dB
– Regulated power supplies to all voltage gain stages
– Independent power supplies for each channel
– Convection cooled and housed in a fully aluminum chassis
– No fans or other moving parts
– Bridging switch configures amplifier into a single 400W Channel

Techninė specifikacija:

Power Capabilities
200W into 8Ω; 300W into 4Ω; 500W into 8Ω (Bridged Mono)

Harmonic Distortion
≤ .005% from 20Hz to 20kHz at 200W

Noise
≤ -112dB @ full bandwidth

Slew Rate
>60V/µS

Power Bandwidth
<1Hz to >100kHz

Damping Factor
>500 at 20Hz (8Ω)

Switchable Gain
23dB or 29dB
