GPA2-800 stereo stiprintuvas - Digital Audio

Ecler
1033 €

Stereo High-efficiency Amplifier

ECLER GPA2-800 is a stereo amplifier delivering 2 x 720 WRMS @ 4 Ω, and ready to drive 2Ω loudspeaker loads (4 x 8 Ω loudspeakers in parallel, per channel). GPA is a series of stereo amplifiers that become a perfect and affordable option in many audio projects. A very high efficiency and an auto standby function provide these amplifiers with a true green profile.

Key Features


  • 2 analogue audio inputs x 2 powered audio outputs
  • Euroblock output and speakon connectors
  • 2 REMOTE volume ports (0-10VDC), compatible with WPm series wall panels
  • High efficiency, auto standby function and convection cooling (fanless, 100% silent)
  • BRIDGE mode ready
  • Thermal protection
  • Overload protection
  • Anti-clip system
  • Volume control knobs on front panel with protection cap, against undesired manipulation

POWER 20-20kHz 1% THD

1 Channel @ 4Ω
640 WRMS

1 Channel @ 8Ω
347 WRMS

All Channels @ 4Ω
575 WRMS

1 Channel @ 2.666Ω
880 WRMS

1 Channel @ 2Ω
1000

2 Bridged Channels @ 8Ω
1150 WRMS

Frequency response (-1 dB, -3dB)
20Hz - 55kHz

Filter (High-Pass) 3rd order Butterworth
50Hz

THD+Noise @ 1kHz Full Power
<0.05%

Intermodulation distorsion 50Hz & 7kHz, 4:1
<0.06%

TIM 100
<0.04%

S+N/N 20Hz - 20kHz @ 1W/4Ω
>85dB

CMRR
>55dB

Damping factor 1 kHz @ 8Ω
>200

Channel crosstalk @ 1kHz
>55dB

Input Sensitivity / Impedance
0dB/<20kΩ

Anticlip @ 2dBV input
<5% THD

Power consumption

pink noise, 1/3 power @ 4Ω
613W

Idle
47W

STBY
16W

Efficiency (typical)
87%

Dimensions (Handle excluded)
440x88x373mm

Weight
13.5kg
