Stereo stiprintuvas su DSP TA 2D - Digital Audio

KS Audio
4840 €
The versatile amplifier with perfect features: from a basic stereo power stage to a digitally controlled 2-way active loudspeaker system with network control and monitoring, any operating mode is possible. Now with F MOD technology! However, the TA 2D finds its best application as high-performance amplifier for all KS woofers. For this purpose, the basic program is ideally matched with configurable parameters to the respective loudspeaker type. NEW: The same technology of the F MOD controller module has been firmly integrated. Thus the amplifier is on the same software level as F MOD and there is the possibility to update new setups and firmware over USB / Ethernet . Also there´s an integrated DANTETM Option. Two independent amplifier channels featuring a highly efficient 3-stage Class-H circuit provide the basic configuration of the TA 2D. Each power output stage comprises 24 fast FET transistors that guarantee superb audio performance with a frequency range of up to 50kHz. The performance of the 2HE/19” amplifier with its 2x2000W is at the upper limit of the energy level that common 16A protected 230V circuits can supply. Already at 8 ohms there are 1,000W available, which is sufficient power to operate almost any loudspeaker. The power stages are supported by a digital audio processor with high-quality 27 bit A/D converters using gain stacking technology. This allows the implementation of 2 single channels, a stereo or a 2-way system. The signal processing programs for all KS full-range loudspeaker systems are equipped with the FIR filter technology FIRTEC. This means individually measured, phase-pure sound reinforcement systems with an unsurpassed sound resolution. Like the F MOD, all current speaker configurations are integrated and all settings can be saved as presets. If new speakers or firmware are available, a complete update can be downloaded from our website into your controller via USB. Modern wide-range switching power supply featuring power factor correction. Technical equipment: 48 FET power transistors with NF-conducted triple operating voltage Regulated switch-mode power adapter with PFC and inrush-current limiting, plus separate standby power supply, loudspeaker outputs with relay power-up delay, protective circuit against low-impedance and electrical overload. Two particularly silent running, temperature-controlled fans
Stereo stiprintuvas su DSP TA 2D

Techninė specifikacija:

number of channels

frequency response + / -1dB (without controlling)
5 – 50,000Hz

output power per channel
4000W peak at 4 Ohms

output impedance
min. 2 ohms per channel

power supply
switchmode power supply with PFC

mains voltage
powercon input (100/250VAC)

amplification mode
Class H MOSFET, 3 rails supply

input connectors
3x XLR3 in, 3x XLR3 out

output connectors
2x speakon NL4

2 fans, speed controlled

stainless steel

charcoal black

dimensions (height x width x depth)
2U / 19“ / 350mm(13.8“)

12 kg

AES/EBU, Ethernet, DANTE option
