D8 pasyvi kolonėlė - Digital Audio

Coda Audio
929 €
The CODA D8 is a 2-way coaxial loudspeaker system designed without compromise to provide a true one point source in an ultra compact package. The cabinet contains a high power 8” woofer and a coaxially mounted neodymium driver with 44.4mm voice coil. The advanced design aligns the acoustical centres of the transducers to produce a single point source. This unique loudspeaker technology provides a coherent wave front without hot spots. Precise directivity of 90° conical ensures uniform coverage with perfect time alignment between the components. Supported with a full range of mounting and flying accessories the D8 sets a state of the art solution for almost any high quality, near field installed sound reinforcement applications.
D8 pasyvi kolonėlė

Techninė specifikacija:

Type
2-way coaxial ultra compact

Application
Superior quality short throw

Frequency response
70 Hz – 20 kHz (-3 dB)

Power handling AES
250 W

Program power
500 W

Peak power
1000 W

Sensitivity
95 dB

Max. SPL peak
124 dB

Dispersion
90° conical

Low frequency
8″ neodymium woofer, 2″ (52 mm) voice coil, 250 W (AES)

High frequency
1″ neodymium driver, 1.75″ (44.4 mm) voice coil, 80 W (AES)

Crossover point
1500 Hz passive

Nominal impedance
16 Ω

100 V version (optional)
100 VA

Input connectors
2x Neutrik™ NL4MP

Enclosure material
12/15mm birch multiplex

Finish
Textured black paint (all RAL-colors optional)

Flying Hardware
M6 threaded points

Dimensions (WxHxD)
230x348x263 mm

Net weight
7 kg
