eHMA60 mikšeris su stiprintuvu - Digital Audio

Ecler
288 €

Powered Mixer

ECLER ESSENTIALS eHMA60 is a self-powered audio mixer including one MIC input and two MIC/LINE ST inputs. It features a 60W powered mono output that supports both low (4 Ω) and high impedance (70V, 100V) loudspeaker lines. It also includes an audio priority system (paging, emergencies, etc.), 2 band tone control, auto stand-by mode, MUTE port, universal power supply unit and auto standby function.

Key Features


  • 1x60W @ 4Ω / 70V / 100V
  • 1 MIC input
  • 2 MIC / LINE inputs (INPUT 1 – Talkover function)
  • 2-band EQ (BASS/TREBLE) for Mix Output
  • 24VDC power supply included
  • 24VDC Phantom Power (external switch)
  • MUTE port to remotely mute the unit from an external device, via dry contact closure
  • Auto Stand-by function

Power output

100V output
60W @ 166Ω 1% THD

Low Z output
66 W @ 4Ω 1% THD

Frequency response (HPF at 70Hz)
70Hz - 30kHz (-3dB)

THD+Noise @ 1kHz Full Power, Speaker Out, Line
<0.08%

Channel crosstalk @ 1 kHz
>65dB

Sensitivity / Nominal impedance

INPUT 1 LINE
-15dBV to + 15dBV / >10 kΩ

INPUT 2 LINE
-15dBV to + 15dBV / >10 kΩ

INPUT 1 MIC
-20dBV to -50dBV / >1 kΩ

INPUT 2 MIC
-20dBV to -50dBV / >1 kΩ

INPUT 3 MIC
-20dBV to -50dBV / >1 kΩ

CMRR

MIC (BAL)
>65dB @ 1kHz

Tone control (LINE & MIC)

BASS
100Hz ±15dB

TREBLE
10kHz ±15dB

Signal Noise Ratio (Gain at center, low Z output)

LINE
>85dB

MIC (BAL)
>75dB

Power consumption

Pink noise, 1/3 power
62 VA / 36W

Standby mode (time 2 minutes)
<4W

Dimensions

Panel WxDxH (knobs excluded)
200x150x44mm

Weight
1.9kg
