Lubinės kolonėlės MXC601

Quest Engineering
242 €
The MXC601 is designed to be a ceiling mount version of the MX wall speaker series. The MX series is a system of audio building blocks that allows architects and venue designers to create a seamless full range audio. The MXC601 can be integrated as part of an MX601 installation and give the same sonic performance in a series or parallel wiring to the MX601 wall speakers. The MXC601 can give extended full range audio coverage when the compact MX10S sub bass is added.


The MXC601 is a premium quality ceiling speaker with a wide range of installation and wiring possibilities. As a 16Ω loudspeaker up to four units can be connected to achieve a 4Ω load to an amplifier. This allows for up to eight speakers to be connected to a stereo amplifier with the result being a very high fidelity distributed system. Multiple 70/100 volt tapings and also an EQ contour can be selected from the front baffle of an installed speaker. This allows for fine tuning after installation if desired.


The aluminium fire resistant casing is acoustically damped and contains a suspension ring on the top of the casing for hanging installation or strain relief. The drivers and internal electronics are identical to the MX601. Like the MX601, The MXC contains a completely new type of woofer design. Quest has designed this new type of driver and incorporated a passive resonance circuit that simulates the action of a reflex port but with a more extended frequency range. The lightweight of the cabinet and neodymium magnet components mean that the weight stress on ceiling tiles is low and reinforcing bars are not required.

Techninė specifikacija:

Max SPL
113dBSPL

Max Power Handling (IEEE219)
240W

Sensitivity
91dB 1W @ 1m

Frequency Response
±2dB 70Hz – 20kHz

Impedance
16 Ω

Transformer Taping
100V-10w/20w/30w/40w; 70V-5w/10w/15w/20w

RMS
75W

Peak
100W

HF
25mm Titanium Dome Tweeter

LF
6” High Performance Polypropylene Woofer

Directivity
130° -10dB

Connections
Captive Screw Terminal Plug (In/Thru)

Cutout Size
254mm Diameter

Dimensions (WxD)
276 x 160mm

Net Weight
2.9 kg
