Hapi keitiklis

The World’s Best Analog Section and Converters... Full Stop. After hundreds of comparison tests made by some of the world’s most “golden eared” engineers, we can say this with a strong sense of confidence. The Networked Audio range of converters brings Swiss-precision and un-ending attention to detail in every single component and signal path and results in the most astonishing of record and reproduction signal paths of any audio interface or converter available today.
  • Hand matched and hand soldered analog componentry.
  • AKM AK5578 A/D chip with modified HPF for enhanced performance (AKD8D/DP)
  • Ardatech AT1201 A/D chip with modified HPF for enhanced performance (AD8D/DP)
  • Individually calibrated quartz clocking mechanism
  • Each channel must pass over 30 noise, distortion, CMRR and level threshold tests
  • Completely balanced signal path direct to the AD
  • A/D and D/A samplerate support from 44.1 -> 384kHz, DXD & DSD64/128/256
Hapi keitiklis

IOC-HAPI Specifications

Case Material
Powder Coated Steel

Front Panel Material
Brushed Aluminum

Weight
4.5 kg

Dimensions (1U rack mounting)
483 x 320 x 44 mm

Power Consumption (Max)
< 30 Watts

Front Panel TFT size/resolution
OLED (160x128 px)

Headphone Monitor Jacks

Max output Level (Unbalanced) Load = 300 Ohms
+14.5 dBu

Output Impedance
75 Ω

Dynamic Range (A-weighted, typ)
112 dB

THD+N (1 kHz) @ -2 dBFS
< -100 dB (0.001 %)

Gain Range (software controlled)
-60 dB to +12 dB

Gain Step/Precision
1dB / ±0.05 dB

Connectors

“Sync” Cable (LTC/Video Ref/MIDI)
D-Sub 15Pin

LTC In & Out (via “Sync” Cable)
Balanced XLR

Video Reference In (via “Sync” Cable)
BNC

MTC (I/O via “Sync” Cable)
5-Pin DIN

Word Clock Input (Switchable 75 Ω Termination)
BNC, 0.5Vp-p min

Word Clock Output (Zout = 35 Ω)
BNC, 5Vp-p

AES type/pinout
DB-25 (Tascam Dig.)

Heaphone Jack 1&2
6.3 mm(1/4”)/3.5mm

RAVENNA Primary / Secondary (GbE)
RJ45
