CF-763SM（R） - Digital Audio
6.3mm Stereo Connector
Furutech’s beautifully finished, beautiful sounding CF-763SM connectors are the result of meticulous engineering and careful audition of various suitable materials. The CF-763SM features a one piece construction α (Alpha) pure copper conductor with audio grade nylon glass fiber resin insulation for minimal impedance and a stainless and carbon fiber finished housing for superior damping.
Main conductor: One-piece Rhodium-plated α (Alpha) Pure copper conductor
Ground conductor: Rhodium-plated α (Alpha) Hybrid Copper conductor
Insulation: Audio Grade Nylon Glass Fiber Resin
Housing: Stainless and carbon fiber finished.
Cable Clamp: Copper Alloy
Specified for core insulation diameters up to 8.0mm
Dimensions: Housing: 14ψx 37.25mm overall length; Total overall length: 70.5 mm approx.
Housing: 14ψx 37.25mm overall length
Total overall length: 70.5 mm approx.
