4 kanalų stiprintuvas PA410

Arcam
1499 €
Exceptional Power, Immersive Sound The PA410 is a high-performance power amplifier that delivers 4 channels of efficient Class AB amplification. With an impressive 70W per channel, the PA410 is designed to offer the greatest flexibility and power without compromising on control. Featuring the best-in-class components including a toroidal based power supply, acoustically damped chassis, paralleled transistor output stages and exceptionally low levels of distortion, the PA410 masters the reproduction of music with all its originality and detail for an unmatched level of sound quality and clarity.


  • 4 Channel Power Amplifier
  • 4 x 50W Class AB amplification (8ohm, 20Hz-20kHz, 0.2% THD)
  • Toroidal transformer
  • Ethernet, RS232 control

Continuous power output at 0.2% THD per channel

Four channels driven, 4Ω / 8Ω, 20Hz – 20kHz
70W / 50W

Two channels driven, 4Ω / 8Ω, 20Hz – 20kHz
90W / 60W

Harmonic distortion, 80% power, 8Ω at 1kHz
0.003%

Inputs

Input sensitivity 50W / 8Ω
600mV RMS

Signal/Noise ratio (A-wtd) 50W / 8Ω
105dB

Input impedance
10kΩ

Frequency response
20 - 20kHz +/-0.05dB

General

Mains voltage
110–120V or 220–240V, 50–60Hz

Power consumption (maximum)
700W

Power consumption (idle, typical)
90W (Thermal dissipation approx. 340 BTU/hour)

Power consumption (standby)
<0.5W

Dimensions W x H x D (including feet, control knob and speaker terminals)
433x325x105 mm

Weight (net)
10kg
