Zamp v.3 stereo stiprintuvas

Parasound
809
  • 45 watts per channel into 8 Ω
  • 60 watts per channel into 4 Ω
  • 90 watts bridged into 8 Ω mono
  • Fully discrete circuitry with Toroid power transformer
  • Low heat design
  • Headphone jack
  • Indicators for AC present and channel operating status
  • Automatic on/off by 9 - 12 V trigger
  • Gold-plated RCA input jacks and looping line output jacks
  • 5-way speaker terminals
  • Compact chassis; 1 rack space high
Zamp v.3 stereo stiprintuvas

Techninė specifikacija

Continuous power output
45 watts RMS x 2, 20 Hz - 20 kHz, 8 Ω, both channels driven; 60 watts RMS x 2, 20 Hz - 20 kHz, 4 Ω, both channels driven; 90 watts RMS x 1, 20 Hz - 20 kHz, 8 Ω, minimum impedance

Current capacity
12 amperes peak per channel

Frequency response
5 Hz - 100 kHz, +0/-3 dB

Total harmonic distortion
< 0.07 % full power; < 0.02 % typical levels

IM distortion
< 0.05 %

Dynamic headroom
1.5 dB

Inter-channel crosstalk
80 dB at 1 kHz; 60 dB at 20 kHz

Input Impedance
33 k Ω

Input Sensitivity
600 mV; 1.5 V for full output

S/N Ratio
116 dB, input shorted, IHF A weighted

Dimensions
8-1/2 w x 1-3/4 h x 10 d, 2 h with feet

Net weight
7 lbs (3.2kg)
